HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment

Product Description
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment factory
Rod bop to prevent the leakage of oil and gas in the recovery operation control device, can guarantee the well-flushing, sand washing, fracturing downhole operation smoothly. By changing different valve core, and can meet the needs of all kinds of rod seal. Product design is reasonable, simple structure, convenient operation, reliable sealing, and long service life and is one of indispensable tools in oil field work.
PRODUCT SPECIFICATIONS
Product Description
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture

The hydraulic BOP stack is used for sealing the annular space between casing and drilling string, or fully sealing wellhead and controlling well pressure during drilling, workovering and testing operation.
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment factory

The product is designed and manufactured in strict
accordance with API Spec 16A and China petroleum industry standard.
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture

According to practice, different sizes of rams, blind rams or shear rams can be used in ram BOP. The ram can be locked manually or hydraulically. The annular BOP has two types of rubber sealing element: spherical and tapered.
Item
Type
Specification


7-1
7-1/16″-3000psi Double ram BOP
Bore: 7-1/16″




Working pressure: 3,000psi


Top connection: 7-1/16″-3000psi 6B R45 SST Studded


Bottom connection: 7-1/16″-3000psi 6B R45 SST Flanged
7-1
7-1/16″-5000psi Double ram BOP
Bore: 7-1/16″




Working pressure: 5,000psi


Top connection: 7 1/16″-5000psi 6B R46 SST Studded


Bottom connection: 7 1/16″-5000psi 6B R46 SST Flanged
7-1
7-1/16″-10000psi Double ram BOP
Bore: 7-1/16"




Working pressure: 10000psi


Top connection: 7 1/16″-10000psi 6BX BX156 SST Studded


Bottom connection: 7 1/16″-10000psi 6BX BX156 SST Flanged
Packing & Shipping
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture
Company Introduction
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture
Shandong Beyond Petroleum Equipment Co., Ltd,
Hereinafter referred to as “Beyond”, was established in year 2016 and certified by
ISO9001. Its main business scope is to supply drilling equipment and spares for overseas customers from different sectors, like petroleum, water well, construction and HDD.
Beyond products cover but not limited to: oil drilling & workover rig, water well drilling rig, pile drilling rig, horizontal directional drilling rig, mud pump and spares, solid control system & equipment, and other different drilling materials.
Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. We can customize the product supply as per your on-site conditions, and we can offer overseas after-sale services with our strong technical support.
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment supplier
Why Choose Us
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment supplier
VR
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture
FAQ
HOT sales API api u type ram blowout preventer for oil Wellhead Control Equipment manufacture







BeyondPetro



The HOT sales API u type ram blowout preventer from BeyondPetro is a piece this vital for almost any oil Wellhead Control gear. Built to offer you security is prevent that maximum disastrous blowouts, this system is becoming one of the most in-demand currently available.


Made out of high-quality materials and technology is higher level this can be an item is reliable of this can withstand extreme conditions and conditions are harsh. It really developed to quickly and effortlessly control any pressure is unexpected which could perhaps happen during drilling and well completion activities.


Fashioned with a body is human assists which are u-shaped the wellbore and avoid any undesired hydrocarbons or contaminants from escaping. Additionally it is designed with rams that may simply be quickly and adjusted to match the style for the wellbore.


One of the features that are top are best of this blowout preventer is its versatility. It’s suitable for utilized in both land-based and operations which can be offshore was developed to satisfy and rise above the stringent standards associated with American Petroleum Institute (API).


Establishing up the product is a piece of cake being a result that total of simple and easy design is user-friendly. It really appropriate with a variety of drilling and well conclusion equipment and can soon easily be incorporated to your operations without producing any interruption.


At BeyondPetro, we comprehend the need for quality and safety in relation to Wellhead Control gear. We have been proud to provide this sales which can be HOT u type ram blowout preventer. Our item is sustained by a united set of experts who is able to be obtained to provide you any assistance or provide you with support may require, ensuring there is the comfort of mind to spotlight your operations.


Do not think twice to get in touch you could be allowed by it to reach your aims with us for more information on BeyondPetro HOT sales API u type ram blowout preventer and exactly how.
